Mini

PUBLIC ADDRESS SYSTEM

The Mini is a wearable, ultra-lightweight PA solution weighing only 2.5 lbs. The optional soft case provides hands-free portability to take your Mini with you anywhere.

This unit can be AC or battery-operated, lasts 10-12 hours on a full charge, and has a convenient optional charging kit. Two wireless microphones and one wired microphone can be used with the Mini. The Mini emits 100 dB of clear, present sound and is ideal for tour guides, first responders, schools, auction houses, and more.

You'll find the Mini used at the San Diego Zoo, on the USS Midway, and at Fenway Park, among other prestigious places.

All Mini systems include:

✅ AC Power

✅ Optional rechargeable battery kit with 11+ hours of playtime

✅ Long-range Bluetooth so you can stream directly to your speaker

✅ One universal wired mic input

✅ Standard Line In and Line Out ports

✅ Anchor Audio 6-4-2 Warranty

Each Liberty 3 speaker:

Weight: 2.6 lbs
Dimensions: (Height x Width x Depth)
7" x 6" x 3.5"
Coverage:
* area: approximately 20' x 30'
* crowd size: approximately 100

Mini speaker components include:

One 4.5" Neodymium Woofer

Technical Specifications

Rated Power Output: 30 watts
Max SPL @ Rated Power: 100 dB @ 1 meter
Frequency Response: 100 Hz ~ 15 kHz ± 3dB
AC Power Reqs:
100~240 VAC, 50/60 Hz, 2A
Charger/Power Inlet: PC-2
Battery
10 AA Alkaline, or 10 Rechargeable Lithium Iron Phosphate (LiFePo4)
AnchorLink Wireless Frequency: 1920~1930 MHz USA/CAN
1880~1900 MHz Europe
AnchorLink Wireless Range: 300’+ line of sight
AnchorFlex Frequency Range:
902~928 MHz USA/CAN
606~614MHz Europe
Microphone Inputs:
* Lo-Z, balanced, XLR & 1/4”
* 34 V DC condenser mic (phantom) power
* Hi-Z (10 kΩ), unbalanced, 1/4” phone
Line Input:
* One 3.5 mm line level
Line Output:
* One 3.5 mm line level

Anchor Audio's 6-4-2 Warranty covers;

All speaker systems for 6 years
Lithium-ion batteries for 4 years, and
Microphones and peripheral products for 2 years.

If your warranty expires, we will not leave you high and dry. We will support you and offer an upgrade path, if you're looking to get new gear.

Looking for the Owner's Manual?

<a href="https://www.anchoraudio.com/hubfs/Guides%2c%20Manuals%2c%20Tech%20Specs/Liberty3-manual-Rev16-110724.pdf">Click here to download the latest Owner's Guide.</a>
