All AN-1000x systems include:
✅ AC Power
✅ One universal wired mic inputs
✅ Standard Line In and Line Out ports
✅ Sturdy, lightweight casing can be mounted on wall with optional bracket mount or on optional speaker stand
✅ Built-in speaker stand socket
✅ Anchor Audio 6-4-2 Warranty
Each Liberty 3 speaker:
- Weight: 45.6 lbs
- Dimensions: (Height x Width x Depth)
9" x 8" x 3"
- Coverage:
* area: approximately 90' x 175'
* crowd size: approximately 250
AN-1000x speaker components include:
- One 14.50" Woofer
- One 10mm Dome Tweeter
Technical Specifications
- Rated Power Output: 50 watts
- Max SPL @ Rated Power: 107 dB @ 1 meter
- Frequency Response: 20 Hz ~ 20 kHz ± 3dB
- AC Power Reqs:
100~240 VAC, 50/60 Hz, 2A
- Charger/Power Inlet: PC-2
- AnchorLink Wireless Frequency: 1920~1930 MHz USA/CAN
1880~1900 MHz Europe
- AnchorLink Wireless Range: 300’+ line of sight
- Microphone Inputs:
* Lo-Z, balanced, XLR & 1/4”
Line Inputs:
* One unbalanced 1/4”
* One 3.5 mm stereo
- Line Output (post fader): Isolated, 600Ω
One 1/4” phone
- Speaker Out: 4-pole Neutrik Speakon® jack
Anchor Audio's 6-4-2 Warranty covers;
- All speaker systems for 6 years
- Lithium-ion batteries for 4 years, and
- Microphones and peripheral products for 2 years.
If your warranty expires, we will not leave you high and dry. We will support you and offer an upgrade path, if you're looking to get new gear.
